Comus International RI-03AA
- RI-03AA
- Comus International
- SWITCH REED SPST-NO 500MA 140V
- Magnetic, Reed Switches
- RI-03AA Datasheet
- -
- -
-
Lead free / RoHS Compliant
- 9051
- Spot Inventory / Athorized Dstributor / Factory Excess Stock
- 1 year quality assurance 》
- Click to get rates
Part Number RI-03AA |
Category Magnetic, Reed Switches |
Manufacturer Comus International |
Description SWITCH REED SPST-NO 500MA 140V |
Package - |
Series RI-03 |
Type Glass Body |
Operating Temperature -55°C ~ 125°C |
Mounting Type Through Hole |
Length - Overall 1.811" (46.00mm) |
Circuit SPST-NO |
Termination Style Axial |
Capacitance 0.3pF |
Operate Range 14 ~ 23AT |
Current - Switching 500mA (AC/DC) |
Voltage - Switching AC 140V |
Voltage - Switching DC 200V |
Power - Rated 10W |
Operate Time 0.25ms |
Release Time 0.03ms |
Size - Body 0.100" Dia x 0.591" L (2.54mm x 15.00mm) |
Current - Carry 1.5A (DC) |
Release Range 6 ~ 21AT |
