YMC14DAAN

Sullins Connector Solutions YMC14DAAN

The picture is for reference only, please refer to the product specification

  • YMC14DAAN
  • Sullins Connector Solutions
  • HI-TEMP CONN HDR .100 DUAL 28POS
  • Rectangular Connectors - Headers, Male Pins
  • YMC14DAAN Datasheet
  • -
  • -
  • Lead free / RoHS CompliantLead free / RoHS Compliant
  • 9726
  • Spot Inventory / Athorized Dstributor / Factory Excess Stock
  • 1 year quality assurance 》
  • Click to get rates
Part Number
YMC14DAAN
Category
Rectangular Connectors - Headers, Male Pins
Manufacturer
Sullins Connector Solutions
Description
HI-TEMP CONN HDR .100 DUAL 28POS
Package
-
Series
-
Operating Temperature
-65°C ~ 250°C
Mounting Type
Through Hole
Termination
Solder
Style
Board to Board or Cable
Current Rating
3A
Contact Material
Beryllium Copper
Number of Positions
28
Connector Type
Header, Breakaway
Number of Positions Loaded
All
Number of Rows
2
Insulation Color
Tan
Contact Type
Male Pin
Fastening Type
Push-Pull
Material Flammability Rating
UL94 V-0
Pitch - Mating
0.100" (2.54mm)
Shrouding
Unshrouded
Contact Length - Mating
0.230" (5.84mm)
Contact Length - Post
0.120" (3.05mm)
Insulation Height
0.100" (2.54mm)
Contact Shape
Square
Contact Finish - Mating
Gold
Contact Finish - Post
Gold
Insulation Material
Polyetheretherketone (PEEK)
Overall Contact Length
0.450" (11.43mm)
Contact Finish Thickness - Mating
30µin (0.76µm)
Row Spacing - Mating
0.100" (2.54mm)

YMC14DAAN Guarantees

jinfftry-guarantee1

jinfftry-guarantee2

jinfftry-guarantee3

• Prompt Responsiveness

• Guaranteed Quality

• Global Access

• Competitive Market Price

• One-Stop support services of supply chain

Jinftry, Your most trustworthy component supplier, welcome to send us the inquiry, thank you!

Do you have any questions about YMC14DAAN ?
Feel free to contact us:

+86-755-28503874
+8615019224070, annies65, +8615118125813
568248857, 827259012, 316249462
+8615019224070, +8615118118839, +8615118125813
( Email first will be appreciative )

Customer reviews

Post your comment

Sullins Connector Solutions
Sullins Connector Solutions
Established in 1971, Sullins Connector Solution is a company with extensive influence in the field of connectors, headquartered in San Marcos, California, USA. Sullins Connector Solutions offers the widest and most diverse range of...
YMC16DAAN
YMC16DAAN

HI-TEMP CONN HDR .100 DUAL 32POS

AMC28DAAN
AMC28DAAN

HI-TEMP CONN HDR .100 DUAL 32POS

YMC35SAAN
YMC35SAAN

HI-TEMP CONN HDR .100 DUAL 32POS

AMC27DAAN
